The pin shaft is made of 42CrMo alloy steel with built-in oil channel,which has high strength and good toughness.
Using the vertical car motor rotation system, 360°rotation, with braking function.The oil cylinder adopts honing tube, which can bear higher pressure and have a longer life
Specifications
| Model | Unit | FC90 | FC160 |
| Weight | kg | 450 | 650 |
| Maximum clamping weigh | kg | 1500 | 2500 |
| Minimum arms round | mm | 1670 | 1835 |
| Min. grabbing diameter | mm | 650 | 700 |
| The largest arms round | mm | 95 | 120 |
| The height of the hold | mm | 985 | 1080 |
| Height at opening | mm | 1240 | 1350 |
| Clip blade width | lon | 510 | 467 |
| Suitable Excavator | ton | 7~10 | 12~16 |
