Product Highlights
1.Optimize cooling system design for Yuchai engine to have better fuel consumption performance.
2.Flip forward engine Hood for Easier Maintenance.
3.Pilot control.
4.ROPS&FOPS Cabin (No. CJ20230105), suspension seat, panoramic cabin for wide visibility.
5.Reliable Braking System, Air-assisted disc foot brake, external drum hand brake.
6.Mature and stable supplying chain from top-quality hydraulic components supplier.
7.Manganese Steel Plates Used for All Structural Components, Ensuring Longevity and Durability.
8.Optional Multiple Attachments Available, Suitable for Harsh and Complex Working Conditions.
Specifications
一、Product Overview
1.ompact size, muti-function design for various working condition.
2.Turbocharged diesel engine, rugged-terrain tires, and reliable driving control system for rugged terrains.
3.crab-steer mode, integrated chassis structure enhances driving stability. Fast speed switching and small turning radius make it more suitable for construction in confined spaces.
4.Hydraulic locks added to the support leg cylinder for increased safety and reliability during operation.
5.Side-shift digging arm for more working conditions
6.New hydraulic steering control system with a proprietary steering program module that allows for switching between three steering modes (front, rear, and all-wheel steering) with minimal angle error, high steering precision, ensuring vehicle stability.
二、Specifications
| Items | Parameters |
| Operating weight | 10500KG |
| Loader lifting capacity | 2500KG |
| Loader Bucket capacity | 1.2m³ |
| Max. hauling force | 86KN |
| Max. digging force | 47KN |
| Gread ability | 26° |
| Loader bucket Max. dumping height | 3050mm |
| Dimension | 6450*2530*3120mm |
| Model | Yuchai |
| Rated power | 75KW |
| RPM | 2200r/min |
| Torque Converter Model | YJ320 |
| Transmission Type | Hydraulic Synchronized Shift for Mechanical Control |
| Number of Gears | F4/R4 |
| Max. traveling Speed | 36km/h |
| Drive Axle | Chinese Made |
| Tire Specifications | 16.9-28 |
| Steering Pressure | 14Mpa |
| Min. Turning Radius | 6950mm |
| Working Pressure | 20Mpa |
| Digging Pressure | 20Mpa |
| Control Method | Hydrulic pilot control |
| Backhoe Bucket Capacity | 0.3m³ |
| Max. dumping height | 4050mm |
| Max. digging depth | 3820mm |
| Max. digging radius | 6528mm |
| Swing Angle | 180° |
| Backhoe Bucket Digging Force | 50KN |
| Boom Digging Force KN | 31 |
