1.Excellent terrain traversal capability
2.Operates in all angles
3.Strong demolition capabilities
4.Remote control
5.Safety
6.Reliability
7.Saving 90% on fuel costs
8. 0 maintenance in 2000 hours
9.LOW failure rate
Download Brochure
Specifications
| Total Weight (Rubber Tracks) | kg | 1850 kg |
| Total Weight (Steel Tracks/Track Pads/Extension Device/Additional Weight each increased by 50kg) | kg | 2050 kg |
| Rated Power | kW/rpm | 24/1454 |
| Voltage/Frequency/Current | V/ Hz/A | 380/50/47 |
| Max. slewing Speed | r/min | 6 |
| Max. Travel Speed | km/h | 2 |
| Max.ground Pressure Ratio | kPa | 33 |
| Noise Power (with/without Breaker) | dB（A） | 87/118 |
| Max. Cradeability | ° | 30 |
| Max.total Traction Forceta | kN | 22 |
| Hydraulic System | Load-Sensitive System | |
| System Rated Flow | L/min | 65.4 |
| Standard System Pressure | Bar | 170 |
| Reinforced System Pressure | Bar | 230 |
| Hydraulic Tank Capacity | L | 32 |
| Control Method | Remote Control (optional) | |
| Remote Control Distance | m | 300(optional) |
| Control System Voltage | V | 24 |
| Hammer Model | SB202 | |
| Hammer Weight | kg | 200 |
| Standard Drill Rod | mm | Φ65×600 |
| Rated Pressure | Bar | 100~150 |
| Rated Flow | L/min | 35~65 |
| Impact Frequency | bpm | 850-1800 |
| A Overall Length | mm | 2400 |
| B Overall Width (folded/unfolded leg) | mm | 780/1080 |
| C Overall Height | mm | 1255 |
| I Ground Length of Tracks | mm | 1045 |
| J Track Length | mm | 1410 |
| V Track Gauge(folded/unfolded leg) | mm | 550/850 |
| W Full Track Width (folded/unfolded leg) | mm | 780/1080 |
| T Track Width | mm | 230 |
| E Height of Counterweight from Ground | mm | 495 |
| F Height of rear panel | mm | 1120 |
| G Min. Ground Clearance | mm | 190 |
| P Tail Length | mm | 720 |
| N Leg Turning Radius | mm | 1000 |
| O Machine Passing Diameter | mm | 1380/1490 |
| K Machine Length | mm | 1930 |
| D Platform Width | mm | 780 |
| H Support Height | mm | 145 |
| S Max. Width of Legs when Open | mm | 2190 |
| X Front and Rear Support Span | mm | 2010 |
| Y Left and Right Support Span | mm | 2030 |
| α Front/Back Departure Angle | ° | 27 |
| AA Max. Operating Radius | mm | 4450 |
| BB Max. Operating Height | mm | 4820 |
| CC Max. Operating Depth | mm | 2110 |
| DD Horizontal Operating Height | mm | 1450 |
| Platform slewing Angle | ° | 360 |
